The Best Seller Machine Product provide Fantastic Discount Eloik ALK-88 Fiber Optic Splicing Machine Fusion Splicer Fusionadora de Fibra Optica. Now USD ~ USD /piece. Dont waste your time. Buy Now only in Good Future Telecom Mall Trusted Seller Store!
Eloik ALK-88 Fiber Optic Splicing Machine Fusion Splicer
Warranty:
ALK-88 fusion splicer warranty is 3 years ,and battery&cleaver frame warranty is 1 year,others accessories warranty is 6 months. About fusion splicer\'s life time warranty,if your machine has some problem,we will help video with you,and understand which part is broken in the warranty time,then we will send this part to you and you could install it. And Eliok will build overseas repair station in future. Of course,Eloik fusion splicer has marketed many sets in China and other countries. The clients are very satisfied with its quality and after sale service. And We will send free multifunction fiber holder to you ! 100% Original and Brand New , Good Price, Good On Line Service , Good After Sale Service , what are you waiting for? Introduction: Eloik ALK-88 Fusion Splicer (portable) Fiber Optic Equipment is a Mini type Fusion splicing machine and have our own intellectual property right of fiber adjustment technology. It adopts advanced PAS Fiber adustment technology . Adopt four motors drive, have fiber adjustment function, it is not only used for FTTX project, but also can be used for the trunk line, it is a machine which is the smallest volume ,the lightest weight ,the most fast splicing speed Features: 1. Hardness:The body is made from titanium alloy , and it has rubber protection function , quakeproof, waterproof, dustproof . 2. Fast: 7s fast splicing , 17s fast heating, support continuous heating , average efficiency improve 2-3times. 3. Long lifetime : 1group batteries. 200 fiber splicing ,no memory effect Lithium Batteries ,the fiber cleaver has 16 blade , long lifetime. 4. Convenience: convenient for maintenance 5. Six languages: Chinese, English, Russian, Portuguese, French, Spanish Specification:| Applicable fiber Type | SM, MM, DS, NZDS |
| Applicable fiber Count | Single |
| Applicable diber diameter | Cladding diameter of 125μm, coating diameter 250~900μm |
| Splice Mode | Stored 40 groups, 80 groups of user-defined |
| Average splice loss | 0.01dB(SM), 0.005dB(MM), 0.04dB(DS), 0.05Db(NZDS) |
| Return Loss | More than 60dB |
| Connecting time | 7sec (typical time) |
| Splice loss evaluation | Have |
| Tensile test | 2N |
| Screen | 4.3inch color LCD |
| Optical magnification | X/Y:115 times, X,or Y: 230 times |
| Power Supply | 11.1V lithium battery, 13.5V/5A power adapter, 12V vehicle power supply |
| Battery | Typical Operating 220(splice/ heat shrink/thermal stripping) on a single charge 3h, can be resued 500 times |
| Maximum storage | 5000 set of the latest record storage |
| Data interface | USB2.0 |
| Operating environment | Altitude 0~4000m, 0 to 95% relative humidity. Temperature -10 oC ~5 oC, the maximum wind speed 15 m/s |
| Storage Conditions | 0 to 95% relative humidity, temperature-40 oC~80 oC(except battery,) temperature -10 oC ~30 oC(battery) |
| Weight | 1.54kgs (without battery), 1.82kgs(including battery), including attachments packing gross weight:5.38kgs |
| Corrosion resistance | Device components, spare parts and materials used meet corrosion requirements, fluid contamination from erosion |
| Size | 150D X 130W X 126H (mm) |
| Packing | New waterproof, drop, more than can be heavy 300kgs |
Package:
| Standard Package | |||
| No. | Description | Quantity | Remark |
| 1 | Optical fiber fusion splicer | 1 | |
| 2 | Power Adapter | 1 | |
| 3 | AC power Line | 1 | |
| 4 | Electrodes | 1 | |
| 5 | Cooler | 1 | |
| 6 | Stripper | 1 | |
| 7 | Miller Clamp | 1 | |
| 8 | Blowing Dust Ball with Brush | 1 | |
| 9 | Specification | 1 | |
| 10 | Optical Fiber Holders | 1 | |
| 11 | Fiber Cleaver | 1 | |
| 12 | Carrying Bag | 1 | |
| 13 | Configuration Checklist Table | 1 | |
PAYMENT
1. We can accept payment via Escrow, Western Union and T/T. The best way is direct online payment,you can choose yourself. If you want to use other payment terms, please let us know before when you order.
2. Full payment must be made within 7 days after placing your order, or the order will be invalid or canceled by the system.
3. Make sure that you have completed all the detailed information like contact person, address, post code and telephone number when filling in your buyer\'s information.
SHIPMENT
1. We will send the goods within 5 business days after the full payment has been confirmed.
2. We can provide the international shipping services as follows:
China Post Air Mail, HK Post Air Mail, EMS, TNT, DHL, UPS, Fedex. The default way is by China post air mail and HK post air mail.
3. The buyer is responsible for insurrance, problems and damage which caused by shipping service such as accidents, delays or other issues. Besides, we are not responsible for any custom duty or import tax, these charges are not included in the item price and shipping cost.
WARRANTY&GUARANTEE
1. All the goods are inspected and tested before shipment. if you are not satisfied with the goods, you can exchange the items within 7 days and you must contact us within 24 hours after the receipt of the items.
2. The shipping and handling charge is not refundable and customer should be responsible for all the charges of returning and reshipping.
3. All return items must be in its original conditions, including box and accessories. Man-made defects are not guaranteed, such as broken, scratched and so on.
4. For any items, please use EMS or your local post when send back
FEEDBACK
1. Buyer\'s early confirmation will be highly appreciated after receiving the items.
2. Since your feedback is very important to our business\'s development, we sincerely invite you to leave positive feedback for us if you are satisfied with our product and service. It\'ll just take you 1 minute, but this 1 minute has the extremely vital significance to us.
3. Please contact us before leaving any negative or neutral feedback. We will work with you to solve any problems.Thank you for your understanding.
Return Policy
If the product you receive is not as described or low quality, the seller promises that you may return it before order completion (when you click "Confirm Order Received" or exceed confirmation timeframe) and receive a full refund. The return shipping fee will be paid by you. Or, you can choose to keep the product and agree the refund amount directly with the seller.N.B.: If the seller provides the "Longer Protection" service on this product, you may ask for refund up to 15 days after order completion.
Seller Service
On-time Delivery: If you do not receive your purchase within 60 days, you can ask for a full refund before order completion (when you click "Confirm Order Received" or exceed confirmation timeframe).Fast Gift Eloik ALK-88 Fiber Optic Splicing Machine Fusion Splicer Fusionadora de Fibra Optica
