High Quality Nema 42 wantai Stepper Motor of 4200oz-in CNC Engraving, Foam Mill and Cutting machines 110BYGH201-001 CE,Rosh

The Best Seller Machine Product provide Terrific Clearance High Quality Nema 42 wantai Stepper Motor of 4200oz-in CNC Engraving, Foam Mill and Cutting machines 110BYGH201-001 CE,Rosh. Now USD ~ USD /piece. Dont waste your time. Buy Now only in wantai motor's store Trusted Seller Store!

Welcome to wantaimotor Store

This item includes:

1 PC Nema 42 Stepper Motor With 4200 OZ-In Holding Torque,8.0A

1, stepper motor

General Specification:

Step angle accuracy: + - 5%(full step,not load)

Resistance accuracy: + - 10%

Inductance accuracy: + - 20%

Temperature rise: 80deg Max(rated current,2 phase on)

Ambient temperature ----------—20deg ~+50deg

Insulation resistance:100MΩ Min,500VDC

Insultion Strength--------500VAC for one minute

Technical Specifications

Part No.: WT110STH201-001

Frame Size: NEMA42

Step Angle: 1.8 degree

Voltage: 5.36VDC

Current: 8.0 A/phase

Resistance: 0.67Ohm/phase

Inductance: 12mH/phase

Holding torque: 300 Kg-cm 4200oz-in

Rotor inertia: 1620 g-cm2

Number of wire leads: 4

Weight: 11.7kgs

Length: 201mm

Shaft Diameter: 19mm

Please tell us if you need Double shaft or single shaft, we can manufacture both for you. If you need Double shaft, please tell us your requirements for length of front and rear shaft, as well as the diameter. So that we can offer you the quite good products, thanks!

Recently we are looking for the distributors and business partners worldwide. Any interest, please feel free to contact us.
