Wantai Nema 34 Stepper Motor with 892OZ-In &Control 3Axis CNC Engraving Machines & Mill

The Best Seller Machine Product provide Cool Flash Deal Wantai Nema 34 Stepper Motor with 892OZ-In &Control 3Axis CNC Engraving Machines & Mill. Now USD ~ USD /piece. Dont waste your time. Buy Now only in wantai motor's store Trusted Seller Store!

Welcome to wantai motor store

This Item includes:

3 PCS Nema 34 Stepper Motor with 892oz-in holding torque,

3 PCS Stepper Motor Driver 80VDC/7.8A Peak Current,256microstep,

1 PC 350W, 48VDC Power Supply

1 PC Breakout Board & 1 Parallel Cable for free offering

1, Stepper Motor

General Specification:

Step angle accuracy: + - 5%(full step,not load)

Resistance accuracy: + - 10%

Inductance accuracy: + - 20%

Temperature rise: 80deg Max(rated current,2 phase on)

Ambient temperature ----------—20deg ~+50deg

Insulation resistance:100MΩ Min,500VDC

Insultion Strength--------500VAC for one minute

1, Technical Specifications

Part No.: 85BYGH450D-007

Frame Size: NEMA34

Step Angle: 1.8 degree

Voltage: 6.4V

Current: 2.0A/phase

Resistance: 3.2 Ohm/phase

Inductance: 15 mH/phase

Holding torque: 6.3N.m 92oz-in (with Bipolar Connecting)

Rotor inertia: 3600g-cm2

Number of wire leads: 8

Weight: 3 kg

Length: 94mm

Please tell us if you need Double shaft or single shaft, we can manufacture both for you. If you need Double shaft, please tell us your requirements for length of front and rear shaft, as well as the diameter. So that we can offer you the quite good products, thanks!

Introduction,Features and Applications

Introduction

The DQ860MA is an economical microstepping driver based on patented technology of Wantai Motor .It is suitable for driving 2-phase 4-phase hybrid stepping motors .By using the advanced bipolar constant-current shopping technique ,it can output more speed and torque from the same motor,compared with traditional drivers ,such as L/R drivers .Its 3-state current control technology allows coil currents to be well controlled and with relatively small current ripple,therefore less motor heating is achieved.

3, Power Supply

350W,48VDC,7.3A

4, DB25 Breakout board & Cable
